RiceTech Machinery - Sorter Super Ultra Series

Model	Output Capacity (TPH)	Weight (Kg)	Power (kW)	Voltage Frequency	Dimension (LxWxH mm)
U4	2.5 - 5.0	1000	3.15	AC 220V 50Hz	1864×1570×2090
U5	3.0 - 5.5	1165	4	AC 220V 50Hz	2184×1570×2090
U7	4.0 - 6.5	1505	5.4	AC 220V 50Hz	2814×1570×2090
U8	5.0 - 7.5	1750	5.8	AC 220V 50Hz	3137×1570×2090
U10	6.0 - 9.0	2050	7	AC 220V 50Hz	3756×1570×2090
U12	7.0 - 10.5	2405	9.8	AC 220V 50Hz	4401×1570×2090

Key Features of Super Ultra Series

Full-Size Screen Operating System: Equipped with a 15-inch high-resolution full-size large screen, this system offers an intuitive interface for seamless operation. Features include one-button boot functionality and remote debugging capabilities, enhancing convenience and efficiency.
Advanced Color Reduction Algorithm: Utilizing AI deep learning technology, this feature ensures clear and accurate color reproduction. The algorithm integrates light, quality, color, and shape to restore the true color of materials, significantly enhancing the precision of color selection.
Double-Row Concentrating LED Light System: The system incorporates a double-row concentrating LED light source with intelligent dimming capabilities. It supports up to 16 million mixed color variations, offering precise lighting control. Designed for energy efficiency and extended durability, it ensures reliable performance in demanding applications.
Multi-Stage Dust Collection System: This advanced system efficiently prevents dust accumulation, significantly reducing maintenance costs associated with dust buildup. Its multi-stage filtration ensures optimal performance and longevity by keeping the system clean and dust-free.

Advanced Camera Image Acquisition System: Equipped with a THOSHIBA CCD linear image sensor, a 5400 CCD industrial lens, and multi-spectral confocal technology, this system delivers an ultra-fine resolution of 0.015mm. It precisely identifies and rejects harmful impurities like glass, while supporting an impressive 16 billion color combinations for outstanding image clarity and color accuracy. The system processes at a rate of 32,400 pixels per second.
High-Speed High-Accuracy Ejector: The integrated structure of this high-frequency solenoid valve allows for precise operation, achieving over 800 cycles per second. This leads to increased output efficiency and reduced energy loss, ensuring superior performance.
Central Positioning and Targeted Rejection: This feature marks the material's center point for precise positioning, significantly improving accuracy. The targeted center rejection system minimizes air consumption, ensuring efficient and sustainable operation.
Reverse Sorting Technology: In the final rejection stage, reverse sorting technology separates good grains from bad grains, reducing the rejection ratio to less than 50:1. This feature enhances profitability and minimizes wastage.
